The evolution of glass to ensure reliability
The semiconductor packaging industry has benefited from glass since the mid-1940’s. For decades precise volumes of molten glass have been reflowed in cylindrical metal cavities with metal center conductors being supported as the glass was allowed to cool below its softening point. Glass-to-metal seals form coaxial and multi-pin feedthroughs that are still used today in high reliability applications as individual connectors or integrated into packages. The feedthrough allows signals to pass into and out of hermetic packages that protect sensitive semiconductors from harsh environments.
Using various material compositions of glass, preforms, made from pressed powder or molten extrusion, are bonded chemically and/or mechanically to specialized alloys providing a robust hermetic solution for a range of applications with rigorous quality standards. Alloys and glass were engineered for mutual compatibility, with the glass specifically formulated to suit the required RF or DC signal type. Glass has fostered confidence in the durability of microelectronic systems, spanning applications from deep-sea to aerospace environments.
The purpose of this background is to highlight undervalued technical gains achieved for functional reliability, while showcasing the sustained, decades-long reliance on glass in challenging operational settings. The development of these high-strength seals also extended product longevity. New materials, processes and equipment were developed to meet more demanding and complex applications. Design, manufacturing and inspection standards evolved to measure hermeticity and assure quality and endurance.
Glass applications in the semiconductor industry are vast, ranging from E-glass fabric in organic laminates to flat-panel displays (FPDs) and specialized micro-optics. It is used as a temporary carrier for handling delicate silicon wafers and as a substrate for photolithography. However, these applications generally perform a single, specific function.
The pursuit of reliable functional density
While organic laminate substrates remain a low-cost method to interconnect premium semiconductor chips, designers shouldn’t be looking at glass substrates through the same economical interconnect lens. Glass substrates can provide an important high-value role that allows more “built-in” functionality and energy efficiency than organic substrate materials. While superior thermomechanical properties have made glass the ‘hot topic’ for next-gen multi-chip modules, its overall market endurance hinges on prioritizing a comprehensive ecosystem to unlock its full, high-utility potential.
Heterogeneous Integration (HI), the combining of more than one semiconductor material fabricated of different process nodes and from different foundries into a single module enables tightly integrated high-performance microsystems. The premise behind HI is to use “the best junction for the function”. Chips of varied pedigree must efficiently communicate with each other through a medium that bonds interconnects reliably.
To improve device reliability, reducing the material count in heterogeneously integrated (HI) multi-chip modules must be a goal of designers. Glass offers a unique unparalleled solution for HI. The Coefficient of Thermal Expansion (CTE) of glass can be tailored to match the die material. Reliable bonds between diverse chips and their respective substrates can be formed. The practice of bonding graded, or cascaded, glass, a series of glass intermediate steps where each step has a slightly different, intermediate CTE dates back before the 1940’s.
With advanced manufacturing, glass can extend the function of the chip. Transferring some of the chip fabrication complexity to the glass substrate improves chip yield. Devices that manage signal and power integrity can be efficiently implemented in the substrate. As the function of the chip and package begins to blur, and Electronic Design Automation (EDA) tools evolve, one material stands out as the appropriate convener allowing chips of different lineage to efficiently communicate: glass.
The industry’s pursuit of maximum functional density has culminated in 3D Heterogeneous Integration (3DHI), a feat of engineering so complex it represents the quintessential DARPA-hard objective.
The challenges of functionally dense 3DHI
The top three challenges of 3DHI in semiconductor packaging:
- Managing thermal dissipation due to high-density stacking,
- Ensuring high-yield, high-precision assembly (wafer/die-to-wafer bonding),
- Maintaining electrical or optical performance (signal/power integrity).
Glass offers solutions in following ways:
- Thermally conductive vias, thermal isolation cavities and coolant passages.
- Ultra flat and smooth surfaces, hybrid bonding to oxide-based RDL and through glass visual alignment.
- Ultra low loss material, thin film, deep trench and through glass integrated passive devices, voltage regulation, integrated RF antennas, filters and waveguides.
Furthermore, the use of glass substrates facilitates key components such as hermetic MEMS, high-frequency RF switches, optical interconnects, and Thin-Film Transistors (TFTs), as well as providing built-in security and long-term memory capabilities. For heterogeneous integration of logic, memory, sensors, analog, and optoelectronics, designers have a full range of glass-based interconnection capabilities to suit various operating environments.
Introducing the Enhanced Functionality Glass Substrate (EFGS™)
A new class of substrate is presented to the packaging community. Enhanced Functionality Glass Substrates (EFGS). Glass substrates with oxide-based redistribution layers (RDLs) to enable submicron and high aspect ratio electrical traces as well as optical and RF waveguides. EFGSs will support hybrid and hermetic bonding while monolithically integrating devices previously mentioned with advanced thermal management and traceability solutions. This monolithic integration at the wafer or panel level shifts the burdens of managing the procurement, storage, security, assembly, inspection and lifecycle of separable components to advanced manufacturing and fabrication processes. The EFGS reduces off shore supply chain dependencies and insecurities but it significantly challenges the design community and the automation of optical and electrical inspections.
The cost and complexity to implement the EFGS is unquestionably higher than the organic laminate substrate or even the silicon interposer but tradeoffs are part of any design cycle. The intense focus on the AI hype cycle obscures the long-term strategic importance of glass substrates as a versatile platform technology with applications far beyond AI.
At FuzeHub, we believe the broad trajectory of Enhanced Functionality Glass Substrates is a long-term platform solution for AI, 6G telecommunications, quantum computing and advanced resonators. FuzeHub is spearheading Glass4Chips (G4C), a U.S.-based consortium initiative, aimed at bridging the gap between the superior technical capabilities of glass and our urgent geopolitical economic priorities.
